Hill Climb Racing Motorcycle
Product parameters
Standard Configuration | |
Engine | ZONGSHEN CBS300, SOHC, Liquid Cooling, Four Stroke, Four Valve, Six Gearshift Balance Shaft |
Displacement | 279.5ml |
Bore×Stroke | 74×65mm |
Max.Power | 18.5/8500kw/(r/min) |
Max.Torque | 23/7000N.m/(r/min) |
Compression Ratio | 10.7：1～11.3：1 |
Lubrication Method | Force-Feed&Splash |
Clutch Mode | Mannual Wet Multi-Plate |
Gearshift Mode | Constant Mesh, 2stage transmission, 6 gearshift |
Ignition mode | Capacitive Energy Storage Type |
Start Mode | Electrical |
Frame | High Strength Steel Tube Frame |
Muffler | Stainless Steel and Aluminum Alloy Backpressure Muffler |
Front Shocks | Invert Upper, Lower Double Damping Front Shock Absorber |
Rear Shocks | Single Chamber, Outter Air-bag Shock Absorber, Upper and Lower Damping Adjustable |
Front Disk Brake | Double Piston Pump Hydraulic Front Brake System |
Rear Disk Brake | Single Piston Pump Hydraulic Rear Brake System |
Forks | Blade Strength Aluminum Alloy Forks |
Rim | Grade 7 High Strength Aluminum Alloy Rim, CNC Drum Core, Front 1.60*21 Rear 2.15*18 |
Tire | XINGUIZUN Deep Tooth Tire, Front 80/100-21 Rear 100/90-18 |
Battery | Colloid Battery 12V6AH |
Length*Width*Height | 2165mm*805mm*1225mm |
Ground Clearance | 300mm |
Seat Height | 920mm |
Fuel Tank Volume | 7L |
Wheel Base | 1440mm |
Curb Weight | 110kg |
Product details
Steering column:
The aluminum alloy high-strength forged steering column has a higher safety factor for precision machining.
Rear fork:
The hill climb racing motorcycle lightweight aluminum alloy blade flat fork is used, which is light and labor-saving, flexible in control and high in safety performance.
Wheels hub:
The use of lightweight CNC front and rear hubs, with CXCL bearings and original dust seals, not only has a texture in appearance, but also has better service life of the hubs and better driving flexibility of the vehicle.
Wheels:
The hill climb racing motorcycle wheel set adopts "7-series" sub-black aluminum alloy ring, with front 21 and rear 18 (80/100-21 100/90-18) Xinguizun original deep gear tires, so that the whole vehicle has better performance on soft land and wetlands. good grip.
