450cc Enduro Motorcycle

The compact structure design of the SHR450 450cc enduro motorcycle engine effectively controls the overall size of the engine; the clutch cover is designed, the clutch disassembly is more convenient.
Send Inquiry
Product Introduction

Product Introduction

The SHR450 model motorcycle is equipped with a 450cc engine, designed for off-road competitions and suitable for long-distance off-road, trails, time trials, and other occasions. "450cc" means 450 cubic centimeters, which is the engine size of some motorcycles. It is most suitable for four-stroke off-road vehicles, because AMA rules for Supercross and Motocross allow bicycles using four-stroke engines to use 450cc engines.



Advantages of 450cc Enduro Motorcycle

The main advantage of the SHR450 enduro motorcycle lies in the engine:



  • The engine structure of the SHR450 model motorcycle is compact, which effectively controls the overall size of the engine.
  • The clutch adopts a cover design, making clutch disassembly and assembly more convenient, and the starter shaft is placed on the upper part, making it more suitable for suspension off-road vehicles.
  • The optimized design of the intake, exhaust, and combustion systems greatly improves the engine's charging efficiency, enhances gas mixing conditions, makes the oil burn more fully, and makes the engine more powerful.
  • The use of needle bearing valve rocker arms improves the friction conditions between the camshaft and the rocker arm, reduces power loss, and increases service life.
  • The built-in balance shaft device effectively balances the vibration of the engine in all directions, ensuring low-noise and stable operation of the engine.



Product Parameters



Standard Configuration

SHR 450

Nc450 single cylinder, water-cooled, four stroke, four valve, overhead cam, balance shaft type

Displacement

449ml

Bore×Stroke

94.5*64mm

Max.Power

30/8000kw/r/min

Max.Torque

37/7000kw/r/min

Compression Ratio

10.7:1

Lubrication Method

Force-Feed&Splash

Clutch Mode

Mannual Wet Multi-Plate

Gearshift Mode

Constant Mesh, 2 stage transmission, 6 gearshift

Ignition mode

Capacitive Energy Storage Type

Start Mode

Electrical& Kick

Frame

High Strength Aluminum Frame

Steering Column

CNC Light Weight High Strength Steering Column

Muffler

Stainless steel aluminum alloy single row muffler

Front Shocks

Fastace dual chamber front shock absorber 54 φ- 60φ

Rear Shocks

Fastace dual cavity rear shock absorber 54 φ- 60φ

Front Disk Brake

Imported Nissin disk, Double Piston Pump Hydraulic Front Brake System

Rear Disk Brake

Imported Nissin disk, Single Piston Pump Hydraulic Rear Brake System

Forks

Blade Strength Aluminum Forks

Rim

Grade 7075 High Strength Aluminum Alloy Rim, CNC hub, Stainless Steel Spoke

Tire

zhengxing, Front 80/100-21 Rear 100/90-18

Battery

Lithium Battery 12V3AH

Length*Width*Height

2160mm*805mm*1250mm

Ground Clearance

300mm

Seat Height

940mm

Fuel Tank Capacity

7L

Wheel Base

1460mm

Curb Weight

116kg





Product Details

12345678

9
